When purchasing SF6 gas recovery and refilling equipment, it must comply with three core categories of international certifications and standards—focused on safety, environmental protection, and technical performance—to ensure compliance with global market access requirements and operational reliability.
1. International Certifications (Third-Party Compliance Validation)
Certifications are mandatory for entering most global markets, as they prove the equipment meets uniform safety and quality benchmarks through third-party verification.
CE Certification (EU & Global Acceptance)Mandatory for sales in the European Union (EU) and widely recognized globally. It covers two key directives for SF6 equipment:
Electromagnetic Compatibility (EMC) Directive (2014/30/EU): Ensures the equipment does not interfere with other electrical devices (e.g., substation control systems) and resists external electromagnetic interference.
Low Voltage Directive (2014/35/EU): Applies to equipment operating at 50–1000V AC or 75–1500V DC, mandating insulation safety, grounding protection, and protection against electric shock.Additionally, compliance with the EU F-Gas Regulation (Regulation (EU) 2024/573) is required alongside CE—this limits SF6 emissions (≤0.1% annual leakage) and bans non-essential SF6 use in certain applications (e.g., medium-voltage switchgear by 2026).
UL Certification (U.S. & North American Market)Required for sales in the United States and Canada. Key relevant standards include:
UL 61010-1: For electrical safety of laboratory and industrial equipment, covering hazard protection (e.g., overcurrent, overheating) for SF6 recovery pumps and control systems.
UL 1203: For explosion-proof equipment, critical if the device is used in hazardous environments (e.g., oil refineries or gas-fired power plants with flammable gases).
ISO 9001 Certification (Global Quality Management)Not a technical performance certification, but a prerequisite for most industrial buyers (e.g., power utilities like Siemens Energy or State Grid). It validates that the manufacturer has a standardized quality management system (QMS) to ensure consistent equipment performance and after-sales support.
2. International Standards (Technical Performance & Environmental Norms)
Standards define specific technical parameters (e.g., recovery efficiency, gas purity) and environmental requirements, serving as the "technical blueprint" for equipment design and testing.
IEC Standards (International Electrotechnical Commission—Core for Electrical Equipment)The most authoritative standards for SF6 gas handling equipment, widely adopted globally:
Weight limits (usually ≤100 kg for easy transport);
Environmental adaptability (operating temperature: -20°C to +40°C);
Vacuum performance (ultimate vacuum ≤1 Pa to ensure thorough gas extraction).
Minimum SF6 recovery rate (≥95% for new equipment);
Post-purification gas quality (moisture ≤50 μL/L, acidity ≤0.2 μL/L as HF);
Prohibition of direct SF6 emission into the atmosphere.
IEC 60480《Specification for the recovery, recycling, purification and charging of sulphur hexafluoride (SF6) gas in gas-insulated equipment》The foundational standard for SF6 recovery and refilling. It mandates:
IEC 61257《Portable sulphur hexafluoride gas recovery devices》Specialized for portable equipment (e.g., on-site substation maintenance units). It specifies:
IEC 60376《Specification for sulphur hexafluoride (SF6) for use in electrical equipment》Defines the purity requirements for SF6 gas (both virgin and recycled) used in electrical equipment—critical for ensuring the recovered gas can be safely refilled into GIS or circuit breakers (e.g., SF6 mass fraction ≥99.9%).
ISO 14064《Greenhouse Gas Accounting and Reporting》Indirectly mandatory for equipment used by enterprises with carbon footprint reporting obligations (e.g., EU ETS participants). It requires the equipment to track SF6 recovery/recycling volumes accurately, enabling enterprises to calculate and report greenhouse gas emission reductions.
IEEE Standards (U.S. & Global Electrical Industry)Relevant for equipment used in power systems, especially in North America and Asia:
IEEE C37.122.1-2017《Standard for Gas-Insulated Switchgear (GIS)》Specifies the compatibility of SF6 refilling equipment with GIS (e.g., pressure control accuracy ±0.02 MPa, connection interface standards) to avoid equipment damage during refilling.
3. Key Consideration: Regional Adaptation of Standards
While international certifications/standards are universal, some regions require additional compliance:
EU: Must align with the F-Gas Regulation (2024/573) (e.g., equipment must have SF6 leakage monitoring functions) and RoHS (restriction of hazardous substances like lead in components).
U.S.: In addition to UL, equipment must meet ANSI/NETA ATS-2021 (standard for acceptance testing of electrical equipment), which includes on-site performance verification of SF6 recovery efficiency.
China: Even for imported equipment, it must comply with national standards equivalent to IEC (e.g., GB/T 15543-2019, equivalent to IEC 60480) and obtain CCC certification (mandatory for electrical products sold in China).
